nat模式实现http和https两种负载均衡集群，每个RS都要提供同一个私钥和同一个证书
安装过程请找脚本 [root@localhost ~]# mkdir /etc/pki/CA [root@localhost ~]# cd /etc/pki/CA/ [root@localhost CA]# mkdir private [root@localhost CA]# (umask 077;openssl genrsa -out private/cakey.pem 2048) Generating RSA private key, 2048 bit long modulus (2 primes) ..............+++++ .................+++++ e is 65537 (0x010001) [root@localhost CA]# openssl req -new -x509 -key private/cakey.pem -out cacert.pem -days 365 You are about to be asked to enter information that will be incorporated into your certificate request. What you are about to enter is what is called a Distinguished Name or a DN. There are quite a few fields but you can leave some blank For some fields there will be a default value, If you enter '.', the field will be left blank. ----- Country Name (2 letter code) [XX]:CN State or Province Name (full name) []:HB Locality Name (eg, city) [Default City]:WH Organization Name (eg, company) [Default Company Ltd]:ZDJ Organizational Unit Name (eg, section) []:ZDJ Common Name (eg, your name or your server's hostname) []:zdj.com Email Address []:1@2.com [root@localhost CA]# mkdir certs newcerts crl [root@localhost CA]# touch index.txt && echo 01 > serial [root@localhost CA]# (umask 077;openssl genrsa -out httpd.key 2048) Generating RSA private key, 2048 bit long modulus (2 primes) ................+++++ ...................+++++ e is 65537 (0x010001) [root@localhost CA]# openssl req -new -key httpd.key -days 365 -out httpd.csr Ignoring -days; not generating a certificate You are about to be asked to enter information that will be incorporated into your certificate request. What you are about to enter is what is called a Distinguished Name or a DN. There are quite a few fields but you can leave some blank For some fields there will be a default value, If you enter '.', the field will be left blank. ----- Country Name (2 letter code) [XX]:CN State or Province Name (full name) []:HB Locality Name (eg, city) [Default City]:WH Organization Name (eg, company) [Default Company Ltd]:ZDJ Organizational Unit Name (eg, section) []:ZDJ Common Name (eg, your name or your server's hostname) []:zdj.com Email Address []:1@2.com Please enter the following 'extra' attributes to be sent with your certificate request A challenge password []:123456 An optional company name []: [root@localhost CA]# openssl ca -in httpd.csr -out httpd.crt -days 365 Using configuration from /etc/pki/tls/openssl.cnf Check that the request matches the signature Signature ok Certificate Details: Serial Number: 1 (0x1) Validity Not Before: Jun 14 14:32:35 2021 GMT Not After : Jun 14 14:32:35 2022 GMT Subject: countryName = CN stateOrProvinceName = HB organizationName = ZDJ organizationalUnitName = ZDJ commonName = zdj.com emailAddress = 1@2.com X509v3 extensions: X509v3 Basic Constraints: CA:FALSE Netscape Comment: OpenSSL Generated Certificate X509v3 Subject Key Identifier: 2A:55:39:2C:01:07:0A:ED:D2:43:57:0C:65:04:C1:20:A8:F6:E4:53 X509v3 Authority Key Identifier: keyid:1B:81:BC:B9:AA:11:D6:68:22:5E:D5:C6:33:E4:AB:25:A9:37:4C:31 Certificate is to be certified until Jun 14 14:32:35 2022 GMT (365 days) Sign the certificate? [y/n]:y 1 out of 1 certificate requests certified, commit? [y/n]y Write out database with 1 new entries Data Base Updated
创建测试index.html
[root@R1 CA]# echo "R1" >/usr/local/apache/htdocs/index.html [root@R2 ~]# echo "R2" >/usr/local/apache/htdocs/index.html
关闭三台机子的防火墙
[root@lb ~]# systemctl disable --now firewalld [root@lb ~]# setenforce 0 [root@R1 CA]# systemctl disable --now firewalld [root@R1 CA]# setenforce 0 [root@R2 ~]# systemctl disable --now firewalld [root@R2 ~]# setenforce 0
在调度器上开启IP转发功能
[root@lb ~]# echo "net.ipv4.ip_forward = 1" >> /etc/sysctl.conf [root@lb ~]# sysctl -p net.ipv4.ip_forward = 1
在调度器上添加并保持规则
[root@lb ~]# ipvsadm -A -t 192.168.100.123:80 -s rr [root@lb ~]# ipvsadm -a -t 192.168.100.123:80 -r 192.168.98.77:80 -m [root@lb ~]# ipvsadm -a -t 192.168.100.123:80 -r 192.168.98.88:80 -m [root@lb ~]# ipvsadm -A -t 192.168.100.123:443 -s rr [root@lb ~]# ipvsadm -a -t 192.168.100.123:443 -r 192.168.98.77:443 -m [root@lb ~]# ipvsadm -a -t 192.168.100.123:443 -r 192.168.98.88:443 -m [root@lb ~]# ipvsadm -Sn > /etc/sysconfig/ipvsadm [root@lb ~]# cat /etc/sysconfig/ipvsadm -A -t 192.168.100.123:80 -s rr -a -t 192.168.100.123:80 -r 192.168.98.77:80 -m -w 1 -a -t 192.168.100.123:80 -r 192.168.98.88:80 -m -w 1 -A -t 192.168.100.123:443 -s rr -a -t 192.168.100.123:443 -r 192.168.98.77:443 -m -w 1 -a -t 192.168.100.123:443 -r 192.168.98.88:443 -m -w 1
设置开机自启
[root@lb ~]# systemctl enable ipvsadm Created symlink /etc/systemd/system/multi-user.target.wants/ipvsadm.service → /usr/lib/systemd/system/ipvsadm.service. [root@lb ~]# echo "ipvsadm -R < /etc/sysconfig/ipvsadm" >>/etc/rc.d/rc.local
将RIP的网关都指向DIP
[root@R1 CA]# cat /etc/sysconfig/network-scripts/ifcfg-ens33 TYPE=Ethernet BOOTPROTO=static NAME=ens33 DEVICE=ens33 ONBOOT=yes IPADDR=192.168.98.77 PREFIX=24 GATEWAY=192.168.98.123 DNS1=114.114.114.114 [root@R2 htdocs]# cat /etc/sysconfig/network-scripts/ifcfg-ens33 TYPE=Ethernet BOOTPROTO=static NAME=ens33 DEVICE=ens33 ONBOOT=yes IPADDR=192.168.98.88 PREFIX=24 GATEWAY=192.168.98.123 DNS1=114.114.114.114
测试效果
[root@lb ~]# curl 192.168.100.123 R1 [root@lb ~]# curl 192.168.100.123 R2 [root@lb ~]# curl 192.168.100.123 R1 [root@lb ~]# curl 192.168.100.123 R2
